6.12 Universal Asynchronous Receiver/Transmitter Controller
Asynchronous serial communication block include 4 UART blocks and accessory logic. They can be
described as follow:
•
UART0
It is merely a general purpose UART. It does not include any accessory function.
Clock Source
: 15MHz
UART Type
: general UART,
FIFO Number
: 16-byte receiving FIFO and 16 byte transmitting FIFO
Modem Function
: N/A
Accessory Function
: N/A
•
UART1
It is designed for general purpose UART or Bluetooth transceiver. It includes a high speed
UART block with 64-byte receiving FIFO and 64-byte transmitting FIFO. It includes 3 clock
sources: 15M, 30M, and 43.6M. Programmer can feel free to choose the clock source and
divisor number for suitable baud rate.
Clock Source
: 15MHz from external crystal
30M, 43.6M, 48M, 60M (optional function for Bluetooth HCI
transport layer)
UAR Type : high speed UART,
FIFO Number : 64-byte receiving FIFO and 64 byte transmitting FIFO
Modem Function : CTS and RTS (optional for Bluetooth. If they were enabled, TX &
RX in UART2 will be cut off)
Accessory Function
: Bluetooth (optional)
Baud Rate (max)
: 1.875MHz
I/O pin : TXD1, RXD1, RTS, CTS (optional)
•
UART2
It is designed for general purpose UART or IrDA SIR. The part of UART includes 16-byte
receiving FIFO and 16-byte transmitting FIFO. The UART has not modem function. The
U3 block has merely 2 I/O. TXD2/RXD2 of UART2 occupy the same pins with RTS and
CTS of UART1. Once the Bluetooth function has been enabled, UART2 should be
disabled.
Clock Source
: 15MHz
UART Type : general UART,
FIFO Number : 16-byte receiving FIFO and 16 byte transmitting FIFO
Modem Function : N/A
