W90P710CD/W90P710CDG
Publication Release Date: September 19, 2006
- 331 -
Revision B2
Accessory Function : IrDA SIR (optional)
I/O Pin : TXD2, RXD2.
I/O Pin Share with : UART1 (Bluetooth function)
•
UART3
It is also merely a general purpose UART. It does not include any accessory function. It
share four I/O pins with AC97/I2S.
Clock Source : 15MHz
UART Type
: general UART,
FIFO Number
: 16-byte receiving FIFO and 16 byte transmitting FIFO
Modem Function
: DTR, DSR
Accessory Function : N/A
I/O Pin
: TXD3, RXD3, DTR, DSR
I/O Pin Share with
: AC97_DATAO, AC97_DATAI, AC97_SYNC, AC97_BITCLK
Table 6.12.1 W90P710 UART features list
BLOCK
NUMBER
UART TYPE
CLOCK
SOURCE
MODEM
FUNCTION
SIGNALS
IO PINS
DESIGN TARGET
0
General
UART
15M N/A
TxD0,
RXD0
General UART
1
High speed
UART
15M, 30M,
43.6M, 48M,
60M
CTS, RTS
TXD1,
RXD1,
CTS1,
RTS1
General UART/
Bluetooth
2
General
UART
15M N/A
TX2,
RX2
General UART/IrDA
SIR
3
General
UART
15M DTR,
DSR
TXD3,
RXD3,
DRT3,
DSR3
General UART
