W90P710CD/W90P710CDG
Publication Release Date: September 19, 2006
- 549 - Revision B2
RTC Control Register Map
REGISTER ADDRESS R/W DESCRIPTION RESET VALUE
RTC_INIR 0xFFF8_4000 R/W RTC Initiation Register -
RTC_AER 0xFFF8_4004 R/W RTC Access Enable Register 0x0000_0000
RTC_FCR 0xFFF8_4008 R/W RTC Frequency Compensation Register 0x0000_0700
RTC_TLR 0xFFF8_400C R/W Time Loading Register 0x0000_0000
RTC_CLR 0xFFF8_4010 R/W Calendar Loading Register 0x0005_0101
RTC_TSSR 0xFFF8_4014 R/W Time Scale Selection Register 0x0000_0001
RTC_DWR 0xFFF8_4018 R/W Day of the Week Register 0x0000_0006
RTC_TAR 0xFFF8_401C R/W Time Alarm Register 0x0000_0000
RTC_CAR 0xFFF8_4020 R/W Calendar Alarm Register 0x0000_0000
RTC_LIR 0xFFF8_4024 R Leap year Indicator Register 0x0000_0000
RTC_RIER 0xFFF8_4028 R/W RTC Interrupt Enable Register 0x0000_0000
RTC_RIIR 0xFFF8_402C R/C RTC Interrupt Indicator Register 0x0000_0000
RTC_TTR 0xFFF8_4030 R/W RTC Tick Time Register 0x0000_0000
Smart card Host Control Register Map
REGISTER ADDRESS R/W DESCRIPTION RESET VALUE
Smartcard Host Interface 0
SCHI_RBR0 0xFFF8_5000(BDLAB=0) R Receiver Buffer Register Undefined
SCHI_TBR0 0xFFF8_5000 (BDLAB=0) W Transmitter Buffer Register Undefined
SCHI_IER0 0xFFF8_5004 (BDLAB=0) R/W Interrupt Enable Register 0x0000_0080
SCHI_ISR0 0xFFF8_5008 (BDLAB=0) R Interrupt Status Register 0x0000_00C1
SCHI_SCFR0 0xFFF8_5008 (BDLAB=0) W Smart card FIFO Control Register 0x0000_0000
SCHI_SCCR0 0xFFF8_500C R/W Smart card Control Register 0x0000_0010
SCHI_CBR0 0xFFF8_5010 R/W Clock Base Register 0x0000_000C
SCHI_SCSR0 0xFFF8_5014 R Smart Card Status Register 0x0000_0060
SCHI_GTR0 0xFFF8_5018 R/W Guard Rime Register 0x0000_0001
SCHI_ECR0 0xFFF8_501C R/W Extended Control Register 0x0000_0052
SCHI_TMR0 0xFFF8_5020 R/W Test Mode Register 0x0000_0000
SCHI_TOC0 0xFFF8_5028 R/W Time out Configuration Register 0x0000_0000
SCHI_TOIR0_0 0xFFF8_502C R/W Time out Initial Register 0 0x0000_0000
SCHI_TOIR1_0 0xFFF8_5030 R/W Time out Initial Register 1 0x0000_0000
SCHI_TOIR2_0 0xFFF8_5034 R/W Time out Initial Register 2 0x0000_0000
