W90P710CD/W90P710CDG
Publication Release Date: September 19, 2006
- 391 - Revision B2
Table 6.16.1 GPIO multiplexed functions table, continued
7 GPIO59 D23 VD15 -
8 GPIO68 nWBE2/SDQM2 - -
9 GPIO69 nWBE3/SDQM3 - -
10 GPIO70 nWAIT nIRQ5 -
PORT5 Configuration Pin Functions
0 GPIO5 TXD0 - -
1 GPIO6 RXD0 - -
2 GPIO7 TXD1 - -
3 GPIO8 RXD1 - -
4 GPIO9 TXD2 CTS1 PS2CLK
5 GPIO10 RXD2 RTS1 PS2DATA
6 GPIO11 SCL0 SFRM TIMER0
7 GPIO12 SDA0 SSPTXD TIMER1
8 GPIO13 SCL1 SCLK KPROW3
9 GPIO14 SDA1 SSPRXD KPROW2
10 GPIO15 nWDOG USBPWREN -
11 GPIO16 nIRQ0 - -
12 GP1O17 nIRQ1 USBOVRCUR -
13 GPIO18 nIRQ2 -
14 GPIO19 nIRQ3 - -
PORT6 Configuration Pin Function
0 GPIO30 VCLK KPROW0 -
1 GPIO31 VDEN KPROW1
2 GPIO32 VSYNC KPROW2 -
3 GPIO33 HSYNC KPROW3 -
4 GPIO34 VD0 KPCOL0 -
5 GPIO35 VD1 KPCOL1 -
6 GPIO36 VD2 KPCOL2 -
7 GPIO37 VD3 KPCOL3 -
8 GPIO38 VD4 KPCOL4 -
9 GPIO39 VD5 KPCOL5 -
10 GPIO40 VD6 KPCOL6 -
11 GPIO41 VD7 KPCOL7 -
