W90P710CD/W90P710CDG
Publication Release Date: September 19, 2006
- 513 -
Revision B2
Continued
BITS
DESCRIPTIONS
[8]
EnCMD
Enable write PS2 Host Controller Commands
This bit enables the write function of Host controller command to
device. Set this bit will start the write process of PS2CMD content
and hardware will automatically clear this bit while write process is
finished.
[7:0]
PS2CMD
PS2 Host Controller Commands
This command filed is sent by the Host to the Keyboard. The most
common command would be the setting/resetting of the Status
Indicators (i.e. the Num lock, Caps Lock & Scroll Lock LEDs).
PS2 Host Controller Status Register (PS2_STS)
REGISTER
ADDRESS
R/W
DESCRIPTION
RESET VALUE
PS2STS 0xFFF8_9004
R/W
Status
register
0x0000_0000
31
30
29
28
27
26
25
24
RESERVED
23
22
21
20
19
18
17
16
RESERVED
15
14
13
12
11
10
9
8
RESERVED
7
6
5
4
3
2
1
0
RESERVED TX_err
TX_IRQ
RESERVED
RX_IRQ
BITS
DESCRIPTIONS
[31:6] RESERVED
-
[5]
TX_err
This Transmit Error Status bit indicates software that device
doesn’t response ACK after Host wrote a command to it.
This bit is valid when TX_IRQ is asserted. It will automatically
reset after software starts next command writing process.
This bit is read only.
[4]
TX_IRQ
This Transmit Complete Interrupt bit indicates software that
the process of Host controller writing command to device is
finished. Software needs to write one to this bit to clear this
interrupt.
