W90P710CD/W90P710CDG
- 252 -
31 30 29 28 27 26 25 24
FBuf0
23 22 21 20 19 18 17 16
FBuf0
15 14 13 12 11 10 9 8
FBuf0
7 6 5 4 3 2 1 0
FBuf0
BITS DESCRIPTIONS
[31:0] FBuf0
Flash Buffer 0
These register ports supports the data read from embedded flash buffer
0. The embedded flash buffer size is 512 bytes, the 128 words.
Consequently, the address range for flash buffer 0 is from 0xFFF0_7400
to 0xFFF0_75FC.
Flash Buffer 1 Registers (FB1_0 ~ FB1_127)
REGISTER ADDRESS R/W DESCRIPTION
RESET
VALUE
FB1_0
…..
FB1_1274 0xFFF0_7800
…..
0xFFF0_79FC
R/W Flash Buffer 1 Undefined
31 30 29 28 27 26 25 24
FBuf1
23 22 21 20 19 18 17 16
FBuf1
15 14 13 12 11 10 9 8
FBuf1
7 6 5 4 3 2 1 0
FBuf1
BITS DESCRIPTIONS
[31:0] FBuf1
Flash Buffer 1
These register ports supports the data read from embedded flash buffer
1. The embedded flash buffer size is 512 bytes, the 128 words.
Consequently, the address range for flash buffer 1 is from 0xFFF0_7800
to 0xFFF0_79FC.
