W90P710CD/W90P710CDG

Publication Release Date: September 19, 2006

- 179 -

Revision B2

Continued.

BITS

DESCRIPTION

[5] FNOE

FrameNumberOverflowEnable
0: Ignore
1: Enable interrupt generation due to Frame Number Overflow.

[4] UREE

UnrecoverableErrorEnable
This event is not implemented. All writes to this bit are ignored.

[3] RDTE

ResumeDetectedEnable
0: Ignore
1: Enable interrupt generation due to Resume Detected.

[2] SOFE

StartOfFrameEnable
0: Ignore
1: Enable interrupt generation due to Start of Frame.

[1] WDHE

WritebackDoneHeadEnable
0: Ignore
1: Enable interrupt generation due to Write-back Done Head.

[0] SCHOE

SchedulingOverrunEnable
0: Ignore
1: Enable interrupt generation due to Scheduling Overrun.

Host Controller Interrupt Disable Register

Writing a ‘1’ to a bit in this register clears the corresponding bit, while writing a ‘0’ to a bit leaves the bit
unchanged.

REGISTER

ADDRESS

R/W

DESCRIPTION

RESET
VALUE

HcInterruptEnable 0xFFF0_5014

R/W Host Controller Interrupt Disable Register

0x0000_0000

MIE

OCE

Reserved

RHSCE

FNOE

UREE

RDTE SOFE WDHE SCHOE
