W90P710CD/W90P710CDG
Publication Release Date: September 19, 2006
- 289 - Revision B2
31 30 29 28 27 26 25 24
DP2[15:8]
23 22 21 20 19 18 17 16
DP2[7:0]
15 14 13 12 11 10 9 8
DP1[15:8]
7 6 5 4 3 2 1 0
DP1[7:0]
BITS DESCRIPTIONS
[31:16] DP2
Recommended pattern value for “4’b0010” gray level
0000 0001 0000 0001
[15:0] DP1
Recommended pattern value for “4’b0001” gray level
0000 0000 0000 0001
Dithering Pattern 2 Register (DITHP2)
REGISTER ADDRESS R/W DESCRIPTION RESET VALUE
DITHP2 0xFFF0_8074 R/W Gray level dithered data duty pattern 2 0x1111_0841
31 30 29 28 27 26 25 24
DP4[15:8]
23 22 21 20 19 18 17 16
DP4[7:0]
15 14 13 12 11 10 9 8
DP3[15:8]
7 6 5 4 3 2 1 0
DP3[7:0]
BITS DESCRIPTIONS
[31:16] DP4
Recommended pattern value for “4’b0100” gray level
0001 0001 0001 0001
[15:0] DP3
Recommended pattern value for “4’b0011” gray level
0000 1000 0100 0001
