W90P710CD/W90P710CDG
Publication Release Date: September 19, 2006
- 547 -
Revision B2
AIC Control Registers Map, continued
REGISTER ADDRESS R/W
DESCRIPTION
RESET
VALUE
AIC_SCR21 0xFFF8_2054 R/W Source Control Register 21
0x0000_0047
AIC_SCR22 0xFFF8_2058 R/W Source Control Register 22
0x0000_0047
AIC_SCR23 0xFFF8_205C R/W Source Control Register 23
0x0000_0047
AIC_SCR24 0xFFF8_2060 R/W Source Control Register 24
0x0000_0047
AIC_SCR25 0xFFF8_2064 R/W Source Control Register 25
0x0000_0047
AIC_SCR26 0xFFF8_2068 R/W Source Control Register 26
0x0000_0047
AIC_SCR27 0xFFF8_206C R/W Source Control Register 27
0x0000_0047
AIC_SCR28 0xFFF8_2070 R/W Source Control Register 28
0x0000_0047
AIC_SCR29 0xFFF8_2074 R/W Source Control Register 29
0x0000_0047
AIC_SCR30 0xFFF8_2078 R/W Source Control Register 30
0x0000_0047
AIC_SCR31 0xFFF8_207C R/W Source Control Register 31
0x0000_0047
AIC_IRSR 0xFFF8_2100 R
Interrupt Raw Status Register
0x0000_0000
AIC_IASR 0xFFF8_2104 R
Interrupt
Active Status Register
0x0000_0000
AIC_ISR 0xFFF8_2108
R
Interrupt Status Register
0x0000_0000
AIC_IPER 0xFFF8_210C R
Interrupt
Priority Encoding Register
0x0000_0000
AIC_ISNR
0xFFF8_2110
R
Interrupt Source Number Register
0x0000_0000
AIC_IMR
0xFFF8_2114
R
Interrupt Mask Register
0x0000_0000
AIC_OISR
0xFFF8_2118
R
Output Interrupt Status Register
0x0000_0000
AIC_MECR
0xFFF8_2120
W
Mask Enable Command Register
Undefined
AIC_MDCR 0xFFF8_2124
W
Mask Disable Command Register
Undefined
AIC_SSCR
0xFFF8_2128
W
Source Set Command Register
Undefined
AIC_SCCR
0xFFF8_212C
W
Source Clear Command Register
Undefined
AIC_EOSCR
0xFFF8_2130
W
End of Service Command Register
Undefined
AIC_TEST 0xFFF8_2200 W
ICE/Debug mode Register
Undefined
