W90P710CD/W90P710CDG
- 408 -
*In the following pin definition, mark with shading is default function.
11 10 01 00
PT4CFG0
Name Type Name Type Name Type Name Type
PORT4_0 RESERVED VD8 O D16 I/O GPIO52 I/O
11 10 01 00
PT4CFG1
Name Type Name Type Name Type Name Type
PORT4_1 RESERVED VD9 O D17 I/O GPIO53 I/O
11 10 01 00
PT4CFG2
Name Type Name Type Name Type Name Type
PORT4_2 RESERVED VD10 O D18 I/O GPIO54 I/O
11 10 01 00
PT4CFG3
Name Type Name Type Name Type Name Type
PORT4_3 RESERVED VD11 O D19 I/O GPIO55 I/O
11 10 01 00
PT4CFG4
Name Type Name Type Name Type Name Type
PORT4_4 RESERVED VD12 O D20 I/O GPIO56 I/O
11 10 01 00
PT4CFG5
Name Type Name Type Name Type Name Type
PORT4_5 RESERVED VD13 O D21 I/O GPIO57 I/O
11 10 01 00
PT4CFG6
Name Type Name Type Name Type Name Type
PORT4_6 RESERVED VD14 O D22 I/O GPIO58 I/O
11 10 01 00
PT4CFG7
Name Type Name Type Name Type Name Type
PORT4_7 RESERVED VD15 O D23 I/O GPIO59 I/O
