446
Appendix B Cable description and NT8D81BA cable replacement
shows the designations for the backplane end of the cables, the
backplane slot designations for the cable connections, and the associated
network segments for the backplane slots.
Table 78
NT8D37 cable connections
Backplane slots–shroud rows
I/O panel/cable designation
L0–1, 2, 3
A
L1–1, 2, 3
B
L2–1, 2, 3
C
L3–1, 2, 3
D
L4–1, 2, 3
E
L5–1, 2, 3
F
L6–1, 2, 3
G
L7–1, 2, 3
H
L8–1, 2, 3
K
L9–1, 2, 3
L
L10–1, 2, 3
M
L11–1, 2, 3
N
L12–1, 2, 3
R
L13–1, 2, 3
S
L14–1, 2, 3
T
L15–1, 2, 3
U
