Page 204

204
Install and configure IP Trunk 3.01 (and later) node
NTCW84KA DCH (P5) connector to the NTAK19FB D-Channel port
connector for Port 1 or Port 3.
4
If the DCHIP card is installed in the expansion cabinet, then use
NTWE04AC SDI/DCH Extension Cable (10 ft) from the NTCW84KA
DCH (P5) connector to the NTAK19FB D-Channel port connector
for Port 1 or Port 3.
—End—
Install the serial cable
Follow the steps in
Procedure 14 "Installing the serial cable" (page 204)
to
install the serial cable.
Procedure 14
Installing the serial cable
Step
Action
1
To make a temporary connection to the IP Trunk 3.01 (and later)
maintenance port from a local RS-232 TTY terminal or a modem,
use the NTAG81CA PC Maintenance cable.
a. Connect the DIN-8 connector to the maintenance port on the
faceplate of the IP trunk card.
b. Connect the DB9 connector to the COM port of a local PC
running TTY terminal emulation.
If required, use an NTAG81BA Maintenance Extender cable to
provide an extension between the NTAG81CA PC Maintenance
cable and the PC COM port. For remote dialup access from a
remote PC, use a null modem adaptor between the NTAG81CA
(or NTAG81BA) maintenance cable and the modem.
2
To make a more permanent connection to the maintenance port:
a. Connect the NTAG81BA Maintenance Extender cable to the
female DB9 connector of the NTCW84KA I/O cable for DCHIP
cards, or the NTMF94EA I/O cable for non-DCHIP cards.
b. Connect the other end of the NTAG81BA Maintenance Extender
cable to the PC COM port, or through a null modem cable to
a modem.
Only a single maintenance port connection can be made at a time.
Do not connect a terminal or modem to the faceplate maintenance
port and the NTCW84KA or the NTMF94EA.
—End—
