Page 414

414
Maintenance
cards have been reset and have correctly rebooted, they respond to
the TM 3.1 IP Trunk 3.01 (and later) status refresh (that is, disabled:
active; disabled: backup: disabled).
13
These cards should remain in the disabled state after the upgrade so
the technician can issue a "Reset" command from the Maintenance
menu or the Maintenance tab in the ITG Card Properties window to
each card to reboot them. Alternatively, reset the cards by pressing
the Reset button on the card faceplate using a pointed object.
14
Double-click each upgraded card and check the software version on
the Configuration tab of the Card Properties.
15
Use the LD 32 ENLC command to re-enable the IP trunk cards.
—End—
Replace an IP trunk card
Following a reboot, if the IP trunk card displays an "F:xx" on the LED
Maintenance Display, this indicates an unrecoverable hardware failure. The
IP trunk card will not register with the system. For a complete listing of
faceplate Maintenance Display codes for the Media Card 32-port trunk card,
see
"Media Card 32-port trunk card faceplate maintenance display codes"
. For a complete listing of faceplate Maintenance Display codes
for the ITG-Pentium 24-port trunk card, see
"ITG-Pentium 24-port trunk card
faceplate maintenance display codes" (page 423)
.
Remove the IP trunk card for two to three seconds and then re-install it. If
the failure continues, replace the card. Follow the steps in
"Replacing an IP trunk card" (page 414)
to replace the card.
Procedure 70
Replacing an IP trunk card
Step
Action
1
Locate the node of the defective IP trunk card:
a. Open the ITG ISDN IP Trunks application in TM 3.1.
b. In the upper part of the IP Telephony Gateway - ISDN IP Trunk
window, click the site name. All the cards in the node are listed
in the lower part of the window.
c. Locate the defective IP trunk card in the lower window by card
TN.
2
Disable the defective IP trunk card in LD 32 using the DISI command.
