Channel Identifier planning 189
Unit number (from TN) ISL Channel number
11 44
12 45
13 46
14 47
15 48
16 49
17 50
18 51
19 52
20 53
21 54
22 55
23 56
Incorrect ISL channel numbering plans
This section describes numbering plan errors.
Gaps in ISL channel numbering sequence
Table 42 "Channel numbering error – gap on one card" (page 189) shows
gaps in the ISL numbering plan sequence. A gap between channel numbers
causes the IP trunk card to be unable to associate the ISL channel number
with the B channel number. Therefore, only units 0 to 4 (loop shelf card 0
to loop shelf card 4) can be used.
Table 42
Channel numbering error, gap on one card
Unit number (from TN) ISL Channel number
0 1
1 2
2 3
3 4
4 5
5 11
6 12
