Install and configure IP Trunk 3.01 (and later) node
In addition to IP Trunk 3.01 (and later) nodes, the IP telephony trunk
network may contain ITG Trunk 1.0 Basic Trunk nodes or Nortel
IP Telephony Connection Manager. Use H.323 V2 node capability
for these nodes.
Quality of Service section
The default setting enables Quality of Service (QoS) monitoring. QoS
monitoring allows new calls to fallback to alternate circuit-switched
trunk routes when the IP network QoS falls below the configured
threshold. If the default setting is changed and QoS monitoring
is disabled, then the IP Trunk 3.01 (and later) node attempts to
complete new calls over the IP network regardless of the IP network
QoS. There can still be alternate routes, but IP Trunk 3.01 (and later)
only uses them if the D-Channel connection to the local IP Trunk
3.01 (and later) node fails, if the destination node fails to respond, or
if the destination node responds that all trunks are busy.
5
To disable QoS monitoring of a destination node, uncheck the
Enable Quality of Service (QoS) monitoring checkbox.
6
Slide the Quality of Service control bar to set the QoS level. The
default setting is 3 (=Good).
See
and
Table 33 "IP Trunk 3.01 (and later) QoS
for more details on QoS levels and MOS values.
—End—
Configure Digits dialed tab
Follow the steps in
Procedure 25 "Configuring the Digits dialed tab" (page
to configure the Digits dialed tab. Use the Digits dialed tab to configure
one or more ESN translations for the current destination node.
"ITG Dialing Plan Remote Node Properties window – Digits dialed tab"
(page 256)
shows the Dialed Digits tab fields.
Procedure 25
Configuring the Digits dialed tab
Step
Action
1
Click the Digits dialed tab.
TM 3.1 displays the Digits dialed tab.
2
Select the ESN translation type from the Dial Plan drop-down list.
Add every ESN translation configured for this destination node in the
ESN (LD 86, LD 87 and LD 96) one at a time.
