NTAG81CA Faceplate Maintenance cable 437
I/O Panel: P1 Signal Name P2, P3, P4, P5 Color
P1-31 P2 SHLD GRND
P1-50 P2 SHLD GRND
P1-23 RXDB+ P3-3 Green/White
P1-48 RXDB- P3-6 White/Green
P1-24 TXDB+ P3-1 Orange/White
P1-49 TXDB- P4-2 White/Orange
P1-18 RX+ P4-3 Green/White
P1-43 RX- P4-6 White/Green
P1-19 TX+ P4-1 Orange/White
P1-44 TX- P4-2 White/Orange
P1-10 P5-2 Black
P1-13 P5-10 Red
P1-11 P5-9 Black
P1-14 P5-11 White
P1-35 P5-4 Black
P1-38 P5-12 Green
P1-36 P5-5 Black
P1-39 P5-13 Blue
P1-12 P5-8 Black
P1-37 P5-15 Yellow
P1-25 P5-1 Black
NC Brown
P1-25 P5 SHLD GRND Bare
P1-50 P5 SHLD GRND Bare
NTAG81CA Faceplate Maintenance cable
The NTAG81CA cable connects an TM 3.1 PC or terminal to the IP trunk
card through the maintenance port connector on the IP trunk card faceplate.
Connect this cable directly to the 9-pin D-type RS-232 input (COM port) on
a standard PC. See
Figure 150 "NTAG81CA PC maintenance cable" (page
438) and Table 73 "NTAG81CA Faceplate Maintenance cable connections"
(page 438) .
