Assess WAN link resources 125
r5 (10.18.0.2) 42 ms 44 ms 38 ms
r4 (10.28.0.3) 78 ms 70 ms 81 ms
r1 (10.3.0.1) 92 ms 90 ms 101 ms
santa_clara_itg4 (10.3.2.7) 94 ms 97 ms 95 ms
The Traceroute program can be used to check if routing in the intranet is
symmetric for each source-destination pair. Use the –g loose source routing
option as shown in the following command syntax:
Richardson3% traceroute -g santa_clara_itg4 richardson3
The Traceroute program identifies the intranet links that transmit IP Trunk
3.01 (and later) traffic. For example, if Traceroute of four site pairs yield
the results shown in
Table 21 "Traceroute identification of intranet links"
(page 125) , then the load of IP Trunk 3.01 (and later) traffic per link can be
computed as shown in Table 22 "Route link traffic estimation" (page 125) .
Table 21
Traceroute identification of intranet links
Site pair Intranet route
Santa Clara/Richardson R1-R4-R5-R6
Santa Clara/Ottawa R1-R2
Santa Clara/Tokyo R1-R4-R5-R7
Richardson/Ottawa R2-R3-R5-R6
Table 22
Route link traffic estimation
Links Traffic from:
R1-R4 Santa Clara/Richardson
+Santa Clara/Tokyo + Ottawa/Tokyo
R4-R5 Santa Clara/Richardson
+Santa Clara/Tokyo + Ottawa/Tokyo
R5-R6 Santa Clara/Richardson
+Richardson/Ottawa
R1-R2 Santa Clara/Ottawa + Tokyo/Ottawa
R5-R7 Santa Clara/Tokyo + Ottawa/Tokyo
R2-R3 Richardson/Ottawa
R3-R5 Richardson/Ottawa
