Retrieve and add an IP Trunk 3.01 (and later) node for maintenance and diagnostic purposes

355

Retrieve IP Trunk 3.01 (and later) configuration information from the IP
Trunk 3.0 (and later) node

Use the optional

Procedure 58 "Retrieving the IP Trunk 3.01 (and later)

configuration data from the IP Trunk 3.01 (and later) node" (page 355)

in the

following situations:

•

when adding an IP Trunk 3.01 (and later) node on TM 3.1 by retrieving
an existing node

•

when it is known that the IP Trunk 3.01 (and later) node configuration
on the IP trunk card is different from the TM 3.1 IP Trunk 3.01 (and
later) database (for example, during maintenance and fault isolation
procedures)

•

when there are multiple TM 3.1 PCs with multiple instances of the
database (administration)

Use the TM 3.1 ITG menu Configuration > Synchronize > Retrieve
command to retrieve the IP Trunk 3.01 (and later) configuration information
from the IP Trunk 3.01 (and later) node.

Procedure 58

Retrieving the IP Trunk 3.01 (and later) configuration data from the IP Trunk
3.01 (and later) node

Step

Action

Launch TM 3.1 and double-click the ITG ISDN IP Trunks icon from
the Services folder. The IP Telephony Gateway - ISDN IP Trunk
window opens.

Select Leader 0 or any card from the node.

Select menu Configuration > Synchronize > Retrieve. The ITG -
Retrieve Options window appears.

Check the boxes for the IP Trunk 3.01 (and later) configuration data
to be retrieved.

Select Node Properties, Card Properties, and Dialing Plan if the
TM 3.1 IP Trunk 3.01 (and later) data is out of date and all TM 3.1 IP
Trunk 3.01 (and later) node data is to be synchronized with the data
from the IP trunk cards on the node.

Select Card Properties to add an IP Trunk 3.01 (and later) node
on TM 3.1 by retrieving from an existing node that contains more
than one card.

Select any combination of check boxes as indicated by problem
symptoms when attempting to isolate a problem on a particular IP
trunk card. Use the "dummy" node for this purpose.
