Install and configure IP Trunk 3.01 (and later) node
Before you begin
Follow the steps in
Procedure 6 "Meeting installation requirements" (page
to ensure that installation requirements are met.
Procedure 6
Meeting installation requirements
Step
Action
1
Install TM 3.1 (and later). Make sure the ITG ISDN IP Trunk and
Alarm Management applications are installed.
2
Upgrade the system software to CS 1000 Release 4.0.
IP Trunk 3.01 (and later) requires package 145 (ISDN) and package
147 (ISL). Install additional software packages, such as package 148
NTWK, as required, for advanced ISDN features.
3
Verify that required LAN and WAN networking equipment and cables
are installed. For networking equipment requirements, refer to
"ITG engineering guidelines" (page 87)
. The IP trunk card requires
shielded cables.
4
Ensure the Media Card 32-port trunk card or ITG-Pentium 24-port
trunk card, DCHIP PC Card (NTWE07), and cable assemblies
required for the site are available.
5
For Large Systems, have the ITG ISL (NT6D80). For Small Systems,
IP Trunk 3.01 (and later) requires at least one available port on an
SDI/DCH card (minimum vintage NTAK02BB). Ensure D-channel
cards have required cables.
6
Verify that the customer site has a Nortel Netgear RM356 Modem
Router (or equivalent) on the ELAN subnet. The modem router
provides remote support access to IP Trunk 3.01 (and later) and
other IP-enabled Nortel products on the system site. See
"Configure a Netgear RM356 modem router for remote access"
(page 459)
for more information on routers.
—End—
