NV9000-SE Utilities • User’s Guide 29
4. Configurations
Importing and Exporting Configurations
By default, archived compressed files are located in C:\Documents and Settings\ [current
user]\My Documents.
How to Import from a Compressed Configuration File
1 Launch NV9000-SE. (See Launching and Exiting the Application on page 12.)
2 From the menu bar, select ‘File’ and then ‘Import from Zip Archive’. The ‘Open’ dialog box
appears:
Figure 4-10. Open Dialog Box
3 Select the compressed file to be opened and click
Open
. The ‘Input’ dialog box appears, as
shown in Figure 4-3.
4 Enter a name for the new configuration in the field provided and click
OK
. The compressed file
contents are decompressed and copied to a new configuration folder. Go to Step 4.
Or
Click
Cancel
to close the dialog box without creating a new configuration.
The configuration data appears in fields on pages when a pane is selected.
