NV9000-SE Utilities • User’s Guide 221
10. Categories
Updating Categories
5 In the same row, select the device being added to the category from the drop-down list in the
‘Device’ column.
6 (Optional) In the ‘Suffix’ columns, select suffixes from the drop-down list.
If the suffix you want is not listed, you can define new suffixes using the ‘Categories’ page,
returning to this procedure once the suffix has been created and saved. (See
Adding Suffixes to
Categories on page 195.)
7 Click
Save
.
Or
To revert to the previously saved configuration, click
Revert to Saved
.
8 Click X on the window title tab to close the table.
Removing Devices from Categories
Removing a device disassociates it from the category; the device remains in the system.
Devices can be removed from categories using the ‘Categories’ page accessed through the ‘Config-
uration’ pane or using the ‘Category Details’ table accessed through the ‘Views’ pane.
How to Remove a Device Using the ‘Category Details’ Page
1 Launch NV9000-SE. (See Launching and Exiting the Application on page 12.)
2 From the Navigation area, select the ‘Configuration’ pane and then ‘Categories’. The ‘Catego-
ries’ page appears, as shown in Figure 10-25.
All categories currently defined in the system are listed. To narrow the list, enter the first char-
acters of the category’s name in the ‘Mnemonic Filter’ field. The list is automatically reduced
to display only categories matching that character string.
Or
From the ‘Level Set Filter’ drop-down list, select a level set. The list is automatically reduced
to display only level sets matching the one selected.
Figure 10-25. Categories Page
3 Double-click on a single row to open details for that category.
