11. Control Panels
Adding a Control Panel
Default
Destination
Last Selected
Panel remembers the last destination
selected and restores this after a reset.
None
After a reset, the control panel displays no
destination device. (Not recommended.)
‹device›
The Panel uses the specified device as the
destination after a reset.
Preset Monitor
None
Monitor the selected preset by defining a
destination that the preset source can be
routed to.
—
‹device›
Status Monitor
None
Selected destination used as a monitor to
switch the source that is in ‘status’ mode
for the selected destination.
—
‹device›
Data
Routing Mode
Automatic
If a data level is involved in the route,
connect the source to the destination,
regardless of who is currently using the
devices.
Semi-automatic
If the device to be acquired is already in
use on the data level, alerts the user
—
but
allows the user to perform the route by
pressing Take a second time. If Take is not
pressed again, the route is cancelled. If the
device is not in use, the take occurs
automatically. Recommended mode.
Manual
All takes on the data level must be
performed manually as breakaways. The
data level will never switch as part of a
multi-level take.
Salvo List
‹salvo›
Select from existing salvos already created
in NV9000 system.
and
Default Name
Set
‹name set›
The name set selected is applied to the
control panel. When a Name Set Toggle
button is added, it toggles between the
default name set and the system name set.
Field
Option
Description
Related Topic
