398 Rev 3.0 • 25 Mar 10
13. EC9700 and EC9710 Panels
Adding an EC9700/EC9710 Panel
How to Add a EC9700/EC9710 Control Panel Using the ‘GUIs’ Table
Panels can be added to configuration files using the ‘GUIs’ table. However, no button configura-
tions can be selected. To define control panel configurations, see
How to Add an EC9700 Control
Panel on page 386 or How to Add an EC9710 Control Panel on page 394.
1 Launch NV9000-SE. (See Launching and Exiting the Application on page 12.)
2 From the Navigation area, select the ‘Views’ pane and then ‘GUIs’. The ‘GUIs’ table appears:
Figure 13-10. GUIs Table
3 Click
Add
. A blank row appears at the end of the list.
4 In the blank row, click on a column to activate the cell and enter information as follows:
5 Click
Save
to save your changes.
Column Description
ID The identification number automatically assigned the control panel in the NV9000-
SE system.
Computer (or
Windows User)
Name
Enter the name of the computer on the network on which the control panel
application resides.
User Name Enter the user’s name. User names are managed through the ‘User’ table. (See
Managing User Names on page 509.)
Configuration From the drop-down list, select a configuration file to associate with the control
panel. For more information on configuration files, see
Working With
Configuration Files on page 19
Language Currently, only English is supported.
Description Enter an optional description of the control panel.
