146 Rev 3.0 • 25 Mar 10
8. Level Sets
Deleting Level Sets
All level sets currently defined in the system are listed. To narrow the list, enter the first charac-
ters of the level set name in the ‘Name Filter’ field. The list is automatically reduced to display
only level sets matching that character string.
Figure 8-29. Level Sets Page
3 From the list of level sets that display, click anywhere in the row listing the level set being
deleted and click
Delete Level Set
. The row is removed from the list.
4 Click
Save
.
Or
To revert to the previously saved configuration, click
Revert to Saved
.
5 Click
X
on the window title tab to close the page.
How to Delete a Level Set Using the ‘Level Sets’ Table
1 Launch NV9000-SE. (See Launching and Exiting the Application on page 12.)
2 From the Navigation area, select the ‘Views’ pane and then ‘Level Sets’. The ‘Level Sets’ table
appears, as shown in Figure 8-30.
