11. Control Panels
Adding a Control Panel
Release Mode
Normal Release
This control panel can only release “locks”
and “protects” set at the control panel itself
(by the assigned user). A user who has the
correct PIN can enable ‘Force Release’
temporarily, allowing the removing of
locks and protects set by any user.
and
and
Force Release
This control panel can release locks and
protects set by any user. Miranda
recommends that you use ‘Normal
Release’ mode and assign a PIN to allow
access to the ‘Force Release’ function.
Default
Destination
Last Selected
Panel remembers the last destination
selected and restores this after a reset.
None
After a reset, the control panel displays no
destination device. (Not recommended.)
‹device›
The Panel uses the specified device as the
destination after a reset.
Preset Monitor
None
Monitor the selected preset by defining a
destination that the preset source can be
routed to.
—
‹device›
Status Monitor
None
Selected destination used as a monitor to
switch the source that is in ‘status’ mode
for the selected destination.
—
‹device›
XY Data
Routing Mode
Automatic
If a data level is involved in the route,
connect the source to the destination,
regardless of who is currently using the
devices.
Semi-automatic
If the device to be acquired is already in
use on the data level, alerts the user
—
but
allows the user to perform the route by
pressing Take a second time. If Take is not
pressed again, the route is cancelled. If the
device is not in use, the take occurs
automatically. Recommended mode.
Manual
All takes on the data level must be
performed manually as breakaways. The
data level will never switch as part of a
multi-level take.
MD Data
Routing Mode
Automatic
If a data level is involved in the multi-
destination route, connect the source to the
destinations, regardless of who is currently
using the devices. (Recommended.)
Manual
All multi-destination takes on the data level
must be performed manually as
breakaways. The data level will never
switch as part of a multi-level take.
Field
Option
Description
Related Topic
