NV9000-SE Utilities • User’s Guide 325
11. Control Panels
Adding a Control Panel
Destination
Protect
All modes Sets or removes a “protect” on current
destination device. The protect can only be
removed at the control panel that originally set
the protect, or by a control panel that has ‘Force
Release’ enabled. A “P” indicates a “protect” on
the display.
Protect on page 363
Free Source All modes Defines a phantom device that can be used to
release or “free” devices on the data (control)
level. A free source is also used with tielines to
free the tieline for others to use. The free source
is configured in the Level Sets page.
Free Source on page
361
and
Level Sets on page
111
Global
Navigate All modes The pages assigned to this button can be
globally applied to every control panel with the
global navigate button. Updates are also global. Global Navigate on
page 361
Hold All modes Retains preset information after Take is pressed.
Useful when routing the same source to many
destinations. Hold on page 361
Information All modes Panel mode is changed to display system
messages. This button toggles between current
control panel mode and the info screen. A “+”
sign indicates messages are present. The Info
button lights when messages are available for
viewing.
Information on page
361
Level Map All modes Cross-connects levels (typically in the same
physical router). Typically used to shuffle audio
channels, for example, to connect AES1/2 to
AES3/4. When an Info button is configured,
you can view current cross-connects. The
‘Level’ mode is cancelled when the next normal
‘Take ‘is performed involving the selected
devices. (The Level Map button becomes
enabled only when there is a valid preset.)
Level Mapping on
page 362
Menu All modes Brings up a menu that provides access to a
variety of local control panel options. The
button is required if you want access to system
menus and “local” salvos.
Menu Mode on page
358
Name Set
Toggle All modes Toggles between the default name set and the
system name set. Name Set Toggle on
page 363
Navigate All modes The ‘Edit Navigate Button’ dialog appears in
which you define a button page that displays
when the button is pressed. See Step 5. —
Page Down All modes Allows scrolling through all data in a list (such
as a category) using the Page Up and Page
Down buttons. The function toggles on/off with
each press of the Scroll button. (A
recommended button.)
—
Page Up All modes
Panel Lock All modes Sets or removes a “lock” on the current control
panel. The lock can only be removed at the
control panel that originally set the lock, or by a
control panel that has ‘Force Release’ enabled.
An “L” indicates a “lock” on the display.
Panel Lock on page
363
Button Modes Description Related Topic
