NV9000-SE Utilities • User’s Guide 235
11. Control Panels
Global Navigation Buttons
in the Global Navigation button editor, then sent (i.e., “pushed”) to the control panels themselves,
and finally implemented through the system controller. For instructions, see
Implementing Config-
uration Changes on page 17.
When a Global Navigation button is deleted, the pages associated with the button are deleted from
any control panel to which the button has been added.
How to Create a Global Navigation Button
1 Launch NV9000-SE. (See Launching and Exiting the Application on page 12.)
2 From the Navigation area, select the ‘Tasks’ pane and then ‘Add Control Panel’.
Or
From the Navigation area, select the ‘Configuration’ pane and then ‘Control Panels’. The ‘Con-
trol Panels’ page displays. On the ‘Control Panels’ page, click Add Control Panel
.
The ‘Add Control Panel’ page appears:
Figure 11-1. Add Control Panel Page
3 Enter information in the fields provided. Entries must be entered in all active fields:
Field Description
Type From the drop-down list, select either NV9640, NV9641 or NV9642. When saved, the
Global Navigation button can be applied to other control panels of the same type
ID Enter a unique identification number up to five digits long. Do not use punctuation
marks or symbols.
Name Enter a unique and descriptive name for the Global Navigation button editor, up to 8
characters long. Do not use punctuation marks or symbols.
