NV9000-SE Utilities • User’s Guide 257
11. Control Panels
Adding a Control Panel
How to configure a NV9603 control panel
1 Add a NV9603 control panel. (See Adding a Control Panel on page 240.)
Or
Locate the NV9603 control panel being updated. (See
How to Locate and View Existing Con-
trol Panels on page 347.) The ‘NV9603’ page appears:
Figure 11-12. NV9603 Page
2 In the ‘Panel Options’ section, select control panel behaviors from the drop-down lists:
Important When configuring the control panel, it is important to select control panel options
first. This determines the subsequent button definitions.
Button Layout section
Button Definitions section
Panel
Options
section
Field Option Description Related Topic
Release Mode Normal Release This control panel can only release “locks”
and “protects” set at the control panel itself
(by the assigned user). A user who has the
correct PIN can enable ‘Force Release’
temporarily, allowing the removing of locks
and protects set by any user.
Locks on page
362
and
Protect on page
363
and
Force Release on
page 360
Force Release This control panel can release locks and
protects set by any user. Miranda
recommends that you use ‘Normal Release’
mode and assign a PIN to allow access to the
‘Force Release’ function.
