236 Rev 3.0 • 25 Mar 10
11. Control Panels
Global Navigation Buttons
4 Click
Navigate
. The ‘Control Panel Details’ page for the type of control panel being configured
appears.
5 Select ‘Navigation’ from the ‘Button Type’ drop-down list. The ‘Edit Navigation Button’ dia-
log box appears:
Figure 11-2. Edit Navigation Button Dialog Box
6 In the ‘Navigation Button Caption’ fields, enter up to three lines of text, 8 characters long. The
text will display on the button on the control panel. Usually the text displays the page name and
button caption.
7 Select a radio button to determine what action occurs when the navigation button is pressed:
• Jump to an Empty New Page – This option creates a new page in the hierarchy. During
operation, the navigation button you are creating causes the control panel to display the
related page. That is, when selected all the buttons predetermined for this page display on
the control panel. After the page is created, you can select it at any time and edit its buttons.
• Jump to an Existing Page – This does not create a new page. Instead this causes the control
panel to display an existing page you have selected from the drop-down list.
• Use Auto-Fill to Create a New Button Page – Activates auto-fill options. Auto fill
automatically generates a number of button assignments on one or more subpages as
defined in the ‘Edit Navigation Button’ dialog box, as shown in Figure 11-47. Go to Step 5.
User By default, only the user type ‘EnvyUser’ is supported at this time. For more
information, see Managing User Names on page 509.
Configuration
Options Select ‘New (default), named’ and enter the name of the Global Navigation button
editor you are creating.
Field Description
