Chapter 6: Software Interface 6–25
Transport and Logical Layer Registers
August 2014 Altera Corporation RapidIO MegaCore Function
User Guide
MSG_REQ_TIMEOUT [25] RW
A required message request has not been received within the
specified time-out interval.
1'b0
PKT_RSP_TIMEOUT [24] RW
A required response has not been received within the specified
time-out interval.
1'b0
UNSOLICIT_RSP [23] RW An unsolicited/unexpected response packet was received. 1'b0
UNSUPPORT_TRAN [22] RW
A transaction is received that is not supported in the Destination
Operations CAR.
1'b0
RSRV [21:8] RO Reserved 22'h0
Implementation Specific
error
[7:0] RO This feature is not supported. 8’b0
Table 6–52. Logical/Transport Layer Error Detect CSR—Offset: 0x10800 (Part 2 of 2)
Field Bits Access Function Default
Table 6–53. Logical/Transport Layer Error Enable CSR—Offset: 0x10804 (Part 1 of 2)
Field Bits Access Function Default
IO_ERROR_RSP_EN [31] RW
Enable reporting of an I/O error response. Save and lock
original request transaction information in all
Logical/Transport Layer Capture CSRs.
1'b0
MSG_ERROR_RESPONSE_EN [30] RW
Enable reporting of a Message error response. Save and
lock original request transaction information in all
Logical/Transport Layer Capture CSRs.
1'b0
GSM error response enable [29] RO This feature is not supported. 1’b0
MSG_FORMAT_ERROR_EN [28] RW
Enable reporting of a message format error. Save and lock
original request transaction information in all
Logical/Transport Layer Capture CSRs.
1’b0
ILL_TRAN_DECODE_EN [27] RW
Enable reporting of an illegal transaction decode error. Save
and lock transaction capture information in
Logical/Transport Layer Device ID and Control Capture
CSRs.
1'b0
ILL_TRAN_TARGET_EN [26] RW
Enable reporting of an illegal transaction target error. Save
and lock transaction capture information in
Logical/Transport Layer Device ID and Control Capture
CSRs.
1'b0
MSG_REQ_TIMEOUT_EN [25] RW
Enable reporting of a Message Request time-out error. Save
and lock original request transaction information in
Logical/Transport Layer Device ID and Control Capture CSRs
for the last Message request segment packet received.
1'b0
PKT_RSP_TIMEOUT_EN [24] RW
Enable reporting of a packet response time-out error. Save
and lock original request address in Logical/Transport Layer
Address Capture CSRs. Save and lock original request
destination ID in Logical/Transport Layer Device ID Capture
CSR.
1'b0
UNSOLICIT_RSP_EN [23] RW
Enable reporting of an unsolicited response error. Save and
lock transaction capture information in Logical/Transport
Layer Device ID and Control Capture CSRs.
1'b0
UNSUPPORT_TRAN_EN [22] RW
Enable report of an unsupported transaction error. Save and
lock transaction capture information in Logical/Transport
Layer Device ID and Control Capture CSRs.
1'b0
