Registers DFFNES
Speedster22i Macro Cell Library Achronix Semiconductor Proprietary PAGE 72
DFFNES
Negative Clock Edge D-Type Register with Clock Enable and
Asynchronous/Synchronous Set
sn
ce
d
ckn
DFFNES
q
Figure 2-11: Logic Symbol
DFFNES is a single D‐type register with data input (d), clock enable (ce), clock (ckn), and
active‐low set (sn) inputs and data (q) output. The active‐low set input overrides all other
inputs when it is asserted low and sets the data output high. The resonse of the q output in
response to the asserted set depends on the value of the sr_assertion parameter and is detailed
in
Table 2‐36: DFFNES Function Table when sr_assertion = “unclocked” and Table
2‐37: DFFNES Function Table when sr_assertion = “clocked” . If the set input is not asserted,
the data output is set to the value on the data input upon the next falling edge of the clock if
the active‐high clock enable input is asserted.
Pins
Table 2-34: Pin Descriptions
Name Type Description
d Data input.
sn
Active-low asynchronous/synchronous set input. A low on sn sets the q
output high independent of the other inputs if the sr_assertion parameter
is set to “unclocked”. If the sr_assertion parameter is set to “clocked”, a low
on sn sets the q output high at the next falling edge of the clock.
ce Active-high clock enable input.
ckn Negative-edge clock input.
q
Data output. The value present on the data input is transferred to the q
output upon the falling edge of the clock if the clock enable input is high
and the set input is high.
Parameters
Table 2-35: Parameters
Parameter Defined Values Default Value
init 1’b1
sr_assertion “unclocked”
init
The init parameter defines the initial value of the output of the DFFNES register. This is the
value the register takes upon the initial application of power to the FPGA. The default value
of the init parameter is 1’b1.
input
input
input
input
output
1’b0, 1’b1
“unclocked”, “clocked”
