Chapter 3 Description
Understanding Logical Element Addressing
Dell PowerVault ML6000 User’s Guide 41
Figure 12 Logical Element
Addressing, 14U, One Partition,
Six Tape Drives Installed
Tape cartridge slots in partition
I/E station slots
Tape drives
Unused slots
Note: Empty drive bay
element addresses are
skipped. This picture
assumes six tape drives are
installed.
