Chapter 12 Installing, Removing, and Replacing
Installing the Library in a Rack
Dell PowerVault ML6000 User’s Guide 349
b Consider removing all tape drives from the module. Modules are
much easier to lift into the rack without the additional weight of
the tape drives.
c
Open the module’s access door and raise the guide pin by pulling
it up and turning it slightly as if it were a screw. Otherwise, the
guide pin may scratch the front doors of the module on which
you are stacking it.
5
Lift the module, align it so that it is parallel with the module below it,
and slide it into place.
6
Lower the module’s guide pin by turning it and pushing it down.
7 Secure the module to the module beneath it by tightening the
thumbscrews located at the base of the front and back of the module.
Press down the thumbscrew, and then tighten it.
1 Guide pin
2 Thumbscrew
