Chapter 12 Installing, Removing, and Replacing
Removing and Replacing the Library Control Blade and LCB Compact Flash Card
Dell PowerVault ML6000 User’s Guide
321
Equipment Required
12
• Ethernet Cable.
• Host PC or laptop connected to the Dell PowerVault ML6000 library.
• Current Dell PowerVault ML6000 library firmware file saved to your
host PC or laptop. Firmware downloads are available at
• Latest library configuration saved on PC or laptop.
Instructions
12
The Compact Flash Card is new and has never been initialized. It contains
only a minimal level of library firmware which allows the library to boot
up and display an Upgrade Notification message. Once you install the
LCB/compact flash card, you will need to upgrade firmware and
reconfigure your network settings.
1
If possible, save the library configuration (see
2
Power off the library.
3
Disconnect all cables from the existing LCB. You may want to label
each cable that is connected to the existing LCB to make sure that you
can correctly reconnect them to the new LCB.
4
Remove the existing LCB from the library.
To remove the existing LCB, release both of the LCB latch hooks and,
using the latch hooks as handles, pull the entire LCB toward you.
Note:
Do not separate the old compact flash card from the library
control blade.
