Dell PowerVault ML6000 - Manual (Page 327)

Chapter 12 Installing, Removing, and Replacing
Removing and Replacing the Library Control Blade and LCB Compact Flash Card
Dell PowerVault ML6000 User’s Guide 327
The progress window displays a “Success” message when complete.
16
Press
Close
.
The next screen lists one or more IP addresses assigned to the library.
17
Write down the IP addresses. You will need them to log in from your
Web browser.
18
Click
Close
.
The system logs you out and you return to the login screen.
19
Open a Web browser on the host PC and type the following in the
address bar:
http:///
where
ipaddress
is one of the IP addresses assigned to the library that
you wrote down earlier.
A screen appears, displaying the current version of library firmware.
Caution:
The installation is NOT complete at this point.
Install current library firmware following the
steps below. Firmware Installation can take up to
1 hour to complete. DO NOT remove power from
the library during this process.
