5–15 Configuring PanelView Terminals
Publication 2711E-6.17 – November 1998
The Rack Number, Module Group, and Last Chassis parameters
enable you to assign the terminal as one of the racks already
configured in the PLC scan list. When replacing an existing
application, you don’t need to reconfigure the PLC before or after
Pass-Through Download if both application files have the same rack
configurations defined.
When you set the Address Source to RIO Pass-Through and choose
OK, the terminal validates the Address Source and saves the
Auto-Restart settings. The terminal also de-selects the current
application file to ensure that the new manual Pass-Through rack
assignment does not conflict with existing application file rack
assignments.
Now when you switch to Run mode, the File Transfer screen is
displayed automatically.
PLC Controllers Required for Pass-Through
Important: Only specific series and revisions of PLC and SLC can
do Pass-Through downloads and uploads. The
following table lists applicable PLCs and SLCs.
Processor Series Revision Valid PLC Racks Baud Rates
SLC-5/04 (requires SLC 5/04
with OS 4.01 and the 1747-SN
Series B Scanner) All All 3 octal 57.6 kbps
115.2 kbps
230.4 kbps
Logix55xx via 1756-DHRIO
Module All — 0 – 76 octal 57.6 kbps
115.2 kbps
230.4 kbps
PLC-5/11 All All 3 octal 57.6 kbps
115.2 kbps
230.4 kbps
PLC-5/15 B N or later 1 – 3 octal 57.6 kbps
PLC-5/20 All All 1 – 3 octal 57.6 kbps
115.2 kbps
230.4 kbps
PLC-5/20C
PLC-5/20C15 All All 1 – 3 octal 57.6 kbps
115.2 kbps
230.4 kbps
PLC-5/20E All All 1 – 3 octal 57.6 kbps
115.2 kbps
230.4 kbps
PLC-5/25 A J or later 1 – 7 octal 57.6 kbps
PLC-5/30 A B or later 1 – 7 octal 57.6 kbps
115.2 kbps
230.4 kbps
