Specifications: 1400e Operator Terminal C–4
Publication 2711E-6.17 – November 1998
Touch Screen Terminals
Membrane: 95% gloss, hard-coated,
scratch-resistant polyester, over
chemically strengthened glass
Bezel: cast aluminum with black powder
coating
Touch cell actuation force: from 2.5 to 3 oz (71 to 85 grams)
Touch Cell Format
•
User can configure to any size touch cell
•
Minimum 40
×
40 pixel touch cell
•
Maximum number of touch cells is 192 (16x12)
Touch cells are rated for 1,000,000 presses.
The following table provides display specifications.
Display Format 640 horizontal by 480 vertical pixels
800 horizontal by 600 vertical pixels
Display Alignment Can be adjusted by the user using HPOS and
VPOS controls.
Display Intensity Low to high range adjustment using contrast and
brightness controls.
Screen Saver User-configurable, 0–60 minute timeout. 0 disables
the screen saver.
Display Size 14-inch diagonal CRT, 247.6 mm
×
185.7 mm
image size
Color Unit Display Attributes
There are 256 fixed colors for screen objects.
Attributes, which are controlled and defined through the software,
include blink and underline. Character sizes include 1
Ч
1
(8
Ч
20 pixels—standard), 1
Ч
2 (8
Ч
40 pixels—double height),
2
Ч
1 (16
Ч
20 pixels—double width), 2
Ч
2 (16
Ч
40—double
height, double width), and 2
Ч
3 (16
Ч
80—extra large).
Degauss
Automatic degauss occurs each time ac power is re-applied to the
unit.
CRT Display
