5–16 Configuring PanelView Terminals
Publication 2711E-6.17 – November 1998
Processor Baud Rates Valid PLC Racks Revision Series
PLC-5/40 A
B E or later
B or later 1 – 17 octal 57.6 kbps
115.2 kbps
230.4 kbps
PLC–5/40C
PLC-5/40C15 All All 1 – 17 octal 57.6 kbps
115.2 kbps
230.4 kbps
PLC-5/40E All All 1 – 17 octal 57.6 kbps
115.2 kbps
230.4 kbps
PLC-5/60 A
B E or later
B or later 1 – 27 octal 57.6 kbps
115.2 kbps
230.4 kbps
PLC-5/60C
PLC-5/60C15 All All 1 – 27 octal 57.6 kbps
115.2 kbps
230.4 kbps
PLC-5/80 All All 1 – 27 octal 57.6 kbps
115.2 kbps
230.4 kbps
PLC-5/80C
PLC-5/80C15 All All 1 – 27 octal 57.6 kbps
115.2 kbps
230.4 kbps
PLC-5/80E All All 1 – 27 octal 57.6 kbps
115.2 kbps
230.4 kbps
PLC-5/250 All All 1 – 37 octal 57.6 kbps
115.2 kbps
230.4 kbps
DH+ Direct/ControlNet Direct
You can upload and download application files over a direct DH+ or
ControlNet link. File transfers over DH+ or ControlNet are initiated
by PanelBuilder or the Transfer Utility and are available in Run
mode only.
For network uploads, if you want to change the current application’s
transfer parameters, see Terminal Network Setup for DH+
Applications or Terminal Network Setup for ControlNet Applications
in this chapter.
For network downloads, if you want to view the current application’s
transfer parameters, see Terminal Network Setup for DH+
Applications or Terminal Network Setup for ControlNet Applications
in this chapter. If you want to change the current application’s
transfer parameters or you do not have a current application selected,
choose the Transfer Setup button, and then select the Network tab in
the Transfer Setup screen.
