5–14 Configuring PanelView Terminals
Publication 2711E-6.17 – November 1998
Selecting Auto Restart
You can choose between Yes and No for the Auto Restart option.
The default setting is No.
•
If you choose Yes, the terminal starts executing the current
application file when the application download completes
successfully. If the downloaded application is made current, it
executes; otherwise the previously running application executes.
•
If you choose No, you must also choose the Resume Run mode
button in the Application Transfer screen.
Setting Address Source
To do a Pass-Through application file transfer, select either
Application or RIO Pass-Through for the Address Source. Network
Direct does not apply to Pass-Through file transfers. If an application
is already selected, the default is Application the first time you enter
this screen. When you re-enter the screen, the values that were
previously saved, appear.
When you set the Address Source to RIO Pass-Through, the current
application file is de-selected. You cannot set the Address Source
back to Application until you select a current application.
Important: After a successful download of an application file using
Pass-Through, the terminal automatically resets the
Address Source to Application, uses the application file
parameters, and discards the Pass-Through parameters.
•
Application
ĊWhen you choose Application, the terminal uses
the current application file’s RIO Pass-Through parameters for
the file transfer. If the current application file contains a
Pass-Through configuration, its values are displayed in the
Terminal Network Setup Racks and Block Transfer Files screens.
The settings in the PanelBuilder application must match the
settings in the Terminal for the application to work correctly.
• RIO PassĆThroughāĊāChoosing RIO Pass-Through Address
Source disables the configuration parameters for the
currently-selected application file. The default settings are
displayed, which you can change if required.
The default settings for the Pass-Through transfer are as follows:
PLC Type PLC 5/25
Baud 57.6K
Rack Number 1
Word 0
Byte Low
Module Group 0, 1
Last Chassis Yes
