2–28 Command Word/Bit Descriptions
Publication 1771-6.5.88 – July 1997
Notes: 1. For [ ] engineering units, see page 3.
2. When using the Inject/Clamp/Eject mode, all pressure readings are system pressure at input 2, except where noted.
Word Description
EAC17 Output #1 Acceleration Ramp Rate during Advance [20]
EAC18 Output #2 Acceleration Ramp Rate during Advance [20]
EAC19 Output #3 Acceleration Ramp Rate during Advance [20]
EAC20 Output #4 Acceleration Ramp Rate during Advance [20]
EAC21 Output #5 Acceleration Ramp Rate during Advance [20]
EAC22 Output #6 Acceleration Ramp Rate during Advance [20]
EAC23 Output #7 Acceleration Ramp Rate during Advance [20]
EAC24 Output #8 Acceleration Ramp Rate during Advance [20]
EAC25 Output #1 Deceleration Ramp Rate during Advance [20]
EAC26 Output #2 Deceleration Ramp Rate during Advance [20]
EAC27 Output #3 Deceleration Ramp Rate during Advance [20]
EAC28 Output #4 Deceleration Ramp Rate during Advance [20]
EAC29 Output #5 Deceleration Ramp Rate during Advance [20]
EAC30 Output #6 Deceleration Ramp Rate during Advance [20]
EAC31 Output #7 Deceleration Ramp Rate during Advance [20]
EAC32 Output #8 Deceleration Ramp Rate during Advance [20]
End of Advance Set-output Values
At the end of each advance stroke during the Ejector Profile, the
module checks the following to determine further control action:
•
state of EPC03-B12
•
states of SYS21-B10 - SYS21-B13
if then the module
EPC03-B12 = 0 ignores EAC33 - EAC40 and continues the Ejector Profile
EPC03-B12 = 1 and
SYS21-B10 through B13 all
bits = 0 uses the ramps EAC17 - EAC32 to move its outputs to
EAC33 - EAC40, and sets status bit SYS22-B14
EPC03-B12 = 1 and
SYS21-B10 through B13 any
bit = 1 ignores EAC33 - EAC40 and gives all output control to
the executing Clamp Open Profile
Word Description
EAC33 Output #1 Set-output Value at End of Advance [19]
EAC34 Output #2 Set-output Value at End of Advance [19]
EAC35 Output #3 Set-output Value at End of Advance [19]
EAC36 Output #4 Set-output Value at End of Advance [19]
EAC37 Output #5 Set-output Value at End of Advance [19]
EAC38 Output #6 Set-output Value at End of Advance [19]
EAC39 Output #7 Set-output Value at End of Advance [19]
EAC40 Output #8 Set-output Value at End of Advance [19]
