Page 230
4–6
Programming Error Codes
Publication 1771-6.5.88 – July 1997
Error Code
Description
ID = 1
0943
MCC43 is too large.
if:
then:
MCC41 and MCC42
MCC43 must be within MCC41 + MCC43 < MCC42 – MCC43
are both non-zero
MCC41 is zero and
MCC43 must be within MCC37 + MCC43 < MCC42 – MCC43
MCC42 is non-zero
MCC41 is non-zero
MCC43 must be within MCC41 + MCC43 < MCC38 – MCC43
and MCC42 is zero
ID = 2
JGC – Jog Configuration Block
Error Code
Description
ID = 2
0209
JGC09 is out of range. Valid range is 00000
≤
JGC09
≤
09999
0210
JGC10 is out of range. Valid range is 00000
≤
JGC10
≤
09999
0211
JGC11 is out of range. Valid range is 00000
≤
JGC11
≤
09999
0212
JGC12 is out of range. Valid range is 00000
≤
JGC12
≤
09999
0213
JGC13 is out of range. Valid range is 00000
≤
JGC13
≤
09999
0214
JGC14 is out of range. Valid range is 00000
≤
JGC14
≤
09999
0215
JGC15 is out of range. Valid range is 00000
≤
JGC15
≤
09999
0216
JGC16 is out of range. Valid range is 00000
≤
JGC16
≤
09999
0217
JGC17 is out of range. Valid range is 00000
≤
JGC17
≤
09999
0218
JGC18 is out of range. Valid range is 00000
≤
JGC18
≤
09999
0219
JGC19 is out of range. Valid range is 00000
≤
JGC19
≤
09999
0220
JGC20 is out of range. Valid range is 00000
≤
JGC20
≤
09999
0221
JGC21 is out of range. Valid range is 00000
≤
JGC21
≤
09999
0222
JGC22 is out of range. Valid range is 00000
≤
JGC22
≤
09999
0223
JGC23 is out of range. Valid range is 00000
≤
JGC23
≤
09999
0224
JGC24 is out of range. Valid range is 00000
≤
JGC24
≤
09999
0225
JGC25 is out of range. Valid range is 00000
≤
JGC25
≤
09999
0226
JGC26 is out of range. Valid range is 00000
≤
JGC26
≤
09999
0227
JGC27 is out of range. Valid range is 00000
≤
JGC27
≤
09999
0228
JGC28 is out of range. Valid range is 00000
≤
JGC28
≤
09999
0229
JGC29 is out of range. Valid range is 00000
≤
JGC29
≤
09999
0230
JGC30 is out of range. Valid range is 00000
≤
JGC30
≤
09999
0231
JGC31 is out of range. Valid range is 00000
≤
JGC31
≤
09999
0232
JGC32 is out of range. Valid range is 00000
≤
JGC32
≤
09999
0233
JGC33 is out of range. Valid range is 00000
≤
JGC33
≤
09999
0234
JGC34 is out of range. Valid range is 00000
≤
JGC34
≤
09999
0235
JGC35 is out of range. Valid range is 00000
≤
JGC35
≤
09999
0236
JGC36 is out of range. Valid range is 00000
≤
JGC36
≤
09999
0237
JGC37 is out of range. Valid range is 00000
≤
JGC37
≤
09999
0238
JGC38 is out of range. Valid range is 00000
≤
JGC38
≤
09999
0239
JGC39 is out of range. Valid range is 00000
≤
JGC39
≤
09999
0240
JGC40 is out of range. Valid range is 00000
≤
JGC40
≤
09999
0241
JGC41 is out of range. Valid range is 00000
≤
JGC41
≤
09999
0242
JGC42 is out of range. Valid range is 00000
≤
JGC42
≤
09999
0243
JGC43 is out of range. Valid range is 00000
≤
JGC43
≤
09999
