Preface P–4
Publication 1771-6.5.88 – May 1997
Reverse Acting
Valve An analog control valve that delivers increasing velocity or
pressure with decreasing signal input
Selected Valve In multi-valve systems, depending on the configured profile, the
QDC module controls one valve and presets the setting of the
remaining valves to produce molding-machine profiles. We call
the valve being controlled by the QDC module’s algorithms the
selected valve. Multiple axes of control, such as the clamp and
ejector cylinders, may require additional control valves.
Status Block Blocks used by the QDC module to report information to the
PLC-5 about the QDC module’s current operating status
SWTL Software travel limit
Unselected Valves In multi-valve systems, depending on the configured profile, the
QDC module controls one valve and presets the remaining
valves to produce molding-machine profiles. We call the valves
that are preset with an open loop percentage setpoint the
unselected valves.
Allen-Bradley offers support services worldwide, with over 75
Sales/Support Offices, 512 authorized Distributors and 260 authorized
Systems Integrators located throughout the United States alone, plus
Allen-Bradley representatives in every major country in the world.
Local Product Support
Contact your local Allen-Bradley representative for:
•
sales and order support
•
product technical training
•
warranty support
•
support service agreements
Technical Product Assistance
If you need to contact Allen-Bradley for technical assistance, please
review the information in the Troubleshooting chapters of User
Manuals 1771-6.85, 1771-6.86, 1771-6.87, and 1771-6.5.93 first.
Then call your local Allen-Bradley representative.
Allen-Bradley Support
