3–46 Status Word/Bit Descriptions
Publication 1771-6.5.88 – July 1997
Notes: 1. For [ ] engineering units, see page 3.
2. When using the Inject/Clamp/Eject mode, all pressure readings are system pressure at input 2, except where noted.
Word Description Bit
B15 = 0 Normal
= 1 End of Ejector Retract Set-Output in Progress
The module sets this bit when holding its outputs to ERC33 - ERC40 after completion of an ejector retract stroke.
The module resets this bit when it receives any new action execution command bit, or when commanded to continue
the ejector profile by DYC03-B15 = 1.
SYS23 Double command error. You can determine from DYC01 which bits were set or downloaded at the same time.
SYS24 Double command error. You can determine from DYC02 which bits were set or downloaded at the same time.
Input Level In Engineering Units
The module reports real-time input levels scaled to engineering units.
Word Description
SYS25 Input #1 [11] or [15]
SYS26 Input #2 [01] or [02] or [03]
SYS27 Input #3 [13] or [25]
SYS28 Input #4 [02] or [04]
SYS29 Input #5 [15]
SYS30 Input #6 [03]
SYS31 Input #7 [25]
SYS32 Input #8 [04]
Input Level, Raw Signal
The module reports real-time signal levels at the input to each A/D
input converter.
Word Description
SYS33 Input #1 [24]
SYS34 Input #2 [24]
SYS35 Input #3 [24]
SYS36 Input #4 [24]
SYS37 Input #5 [24]
SYS38 Input #6 [24]
SYS39 Input #7 [24]
SYS40 Input #8 [24]
Output Level in Percentage
The module reports real-time output percentage it sends to each D/A
output converter.
Word Description
SYS41 Output #1 [19]
SYS42 Output #2 [19]
SYS43 Output #3 [19]
SYS44 Output #4 [19]
SYS45 Output #5 [19]
SYS46 Output #6 [19]
SYS47 Output #7 [19]
SYS48 Output #8 [19]
