3–5 Status Word/Bit Descriptions
Publication 1771-6.5.88 – July 1997
CLS
Bit-mapped Status Words
Word Description
CLS01 Block ID = 00001001 (Low byte). High byte identical to SYS01
CLS02 See SYS02
CLS03 See SYS03
CLS04 See SYS04
CLS05 - 08 Open
Clamp Close Profiles ERC Actuals
Word Description
CLS09 Segment 1 (First Clamp Close Profile)
CLS10 Segment 2 (First Clamp Close Profile)
CLS11 Segment 3 (First Clamp Close Profile)
CLS12 Segment 4 (Second Clamp Close Profile)
CLS13 Segment 5 (Second Clamp Close Profile)
CLS14 Segment 6 (Second Clamp Close Profile)
CLS15 Segment 7 (Third Clamp Close Profile)
CLS16 Segment 8 (Third Clamp Close Profile)
CLS17 Segment 9 (Third Clamp Close Profile)
CLS18 Segment 1 (Clamp Low Pressure Close Profile)
CLS19 Segment 2 (Clamp Low Pressure Close Profile)
Clamp Open Profiles ERC Actuals
Word Description
CLS20 Segment 1 (First Clamp Open Profile)
CLS21 Segment 2 (First Clamp Open Profile)
CLS22 Segment 3 (First Clamp Open Profile)
CLS23 Segment 4 (Second Clamp Open Profile)
CLS24 Segment 5 (Second Clamp Open Profile)
CLS25 Segment 6 (Second Clamp Open Profile)
CLS26 Segment 7 (Third Clamp Open Profile)
CLS27 Segment 8 (Third Clamp Open Profile)
CLS28 Segment 9 (Third Clamp Open Profile)
CLS29 Segment 1 (Clamp Open Slow Profile)
CLS30 Segment 2 (Clamp Open Slow Profile)
Ejector Profile ERC Actuals
Word Description
CLS31 Ejector Full Advance Segment 1
CLS32 Ejector Full Advance Segment 2
CLS33 Ejector Full Advance Segment 3
CLS34 Reserved
CLS35 Ejector Tip Retract Segment
CLS36 Reserved
CLS – Clamp and Eject
ERC Values Status Block
