2–68 Command Word/Bit Descriptions
Publication 1771-6.5.88 – July 1997
Notes: 1. For [ ] engineering units, see page 3.
2. When using the Inject/Clamp/Eject mode, all pressure readings are system pressure at input 2, except where noted.
Bit-mapped Control Words
Word Bit Description
MCC01 B00 - B07 Block ID 00000001
B08 - B15 Reserved for the module. Do not use.
MCC02 MCC Configuration Selections
B00 Data Range Selection
0 English Units (Inches and PSI) 0 = English Units (Inches and PSI)
1 = Metric Units (Millimeters and Bar)
B01 Module designation for co-injection
0 = QIA
1 = QIB
B02 Open
B03 Module I/O Density B03 Module I/O Density
0 = invalid 0 = invalid
1 = Four/Four I/O (required selection)
Four/Four I/O Configuration Four/Four I/O Configuration
MUST BE SET. The module configures itself as a 1-slot module containing four inputs and four outputs, MUST BE SET. The module configures itself as a 1 slot module containing four in uts and four out uts,
and accesses bits MCC02-B04 and MCC02-B05 to determine layout of its inputs.
B04 -B05 B05 B04 Four/Four I/O Configuration
0 0 Inject Control
0 1 Inject and Clamp Control
1 0 Clamp and Eject Control 1 0 Clam and Eject Control
1 1 Inject, Clamp, and Eject Control
B05 B04 Input #1 Input #2 Input #3 Input #4
0 0 Ram (Screw) Position Ram (Screw) Pressure Screw RPM Cavity Pressure
0 1 R (S ) P iti R (S ) P Cl P iti Cl P
( ) ( ) y
0 1 Ram (Screw) Position Ram (Screw) Pressure Clamp Position Clamp Pressure
1 0 Ejector Position Ejector Pressure Clamp Position Clamp Pressure
1 1 Ram (Screw) Position System Pressure Clamp Position Ejector Position
The module accesses these bits only if MCC02-B03 is SET.
B06-B07 Open
B08 inhibit (override) loss of sensor protection for screw position input
B09 Inhibit (override) loss of sensor protection for screw pressure input
B10 Inhibit (override) loss of sensor protection for clamp position input
B11 Inhibit (override) loss of sensor protection for clamp pressure input
B12 Inhibit (override) loss of sensor protection for ejector position input
B13 Inhibit (override) loss of sensor protection for ejector pressure input
B14 Inhibit (override) loss of sensor protection for screw RPM input
B15 Inhibit (override) loss of sensor protection for cavity pressure input (system pressure in Inject-Clamp-Eject mode)
MCC – Module Configuration
Command Block
