2–103 Command Word/Bit Descriptions
Publication 1771-6.5.88 – July 1997
SOC
End of Profile Set-output Values
When the module completes the Second Clamp Open Profile and
OPC03-B09 is SET and SYS21-B14 is RESET, it:
•
sets its outputs to the values listed below
•
sets status bit SYS22-B11
•
ignores SYS22 and these values and gives output control to the
Ejector Profile if SYS21-B14 is SET
•
uses ramp rates SOC17 - 32 when changing outputs to these value
Use these values for pulling cores if applied before starting the Third
Clamp Open Profile.
Word Description
SOC33 Output #1 Set-output Value at End of Profile [19]
SOC34 Output #2 Set-output Value at End of Profile [19]
SOC35 Output #3 Set-output Value at End of Profile [19]
SOC36 Output #4 Set-output Value at End of Profile [19]
SOC37 Output #5 Set-output Value at End of Profile [19]
SOC38 Output #6 Set-output Value at End of Profile [19]
SOC39 Output #7 Set-output Value at End of Profile [19]
SOC40 Output #8 Set-output Value at End of Profile [19]
Pressure Control Limits
Word Description
SOC41 Pressure Minimum Control Limit [02] Minimum controllable clamp pressure attainable during any Press/Pos Second Clamp Open
Profile. The module expects this clamp pressure when setting its selected pressure valve to the %-output in SOC43.
SOC42 Pressure Maximum Control Limit [02] Maximum controllable clamp pressure attainable during any Press/Pos Second Clamp Open
Profile. The module expects this clamp pressure when setting its selected pressure valve to the %-output in SOC44.
SOC43 Selected Pressure Valve Output for Minimum [19] 0% CV output percentage that the module uses to drive the selected pressure
valve during any Press/Pos Second Clamp Open Profile. The module expects a pressure equal to SOC41 when setting the selected
pressure valve to this %-output during profile execution. The Press/Pos Second Clamp Open Profile will be executed as a reverse-
acting algorithm if this entry is greater than SOC44.
SOC44 Selected Pressure Valve Output for Maximum [19] 100% CV output percentage that the module uses to drive the selected pressure
valve during any Press/Pos Second Clamp Open Profile. The module expects a pressure equal to SOC42 when setting the selected
pressure valve to this %-output during profile execution. The Press/Pos Second Clamp Open Profile will be executed as a reverse-
acting algorithm if this entry is less than SOC43.
Velocity Control Limits
Word Description
SOC45 Velocity Minimum Control Limit [08] Minimum controllable clamp velocity attainable during any Vel/Pos Second Clamp Open Profile.
The module expects this clamp velocity when setting its selected velocity valve to the %-output in SOC47.
SOC46 Velocity Maximum Control Limit [08] Maximum controllable clamp velocity attainable during any Vel/Pos Second Clamp Open Profi-
le. The module expects this clamp velocity when setting its selected velocity valve to the %-output in SOC48.
SOC47 Selected Velocity Valve Output for Minimum [19] 0% CV output percentage that the module uses to drive the selected velocity valve
during any Vel/Pos Second Clamp Open Profile. The module expects a velocity equal to SOC45 when setting the selected velocity
valve to this %-output during profile execution. The Vel/Pos Second Clamp Open Profile will be executed as a reverse-acting algo-
rithm if this entry is greater than SOC48.
SOC48 Selected Velocity Valve Output for Maximum [19] 100% CV output percentage that the module uses to drive the selected velocity
valve during any Vel/Pos Second Clamp Open Profile. The module expects a velocity equal to SOC46 when setting the selected
velocity valve to this %-output during profile execution. The Vel/Pos Second Clamp Open Profile will be executed as a reverse-act-
ing algorithm if this entry is less than SOC47.
