Chapter
1
Publication 1771-6.5.88 – July 1997
Abbreviated Command and
Status Blocks
Use this chapter as a quick reference to word descriptions and
Pro-Set addresses of all data blocks used by the QDC module.
For complete word and bit descriptions of these data blocks,
see Chapter 3 (command) and Chapter 4 (status).
The following tables list command and status blocks in this chapter
by page number. Blocks are presented in abbreviated format.
Addresses are for both Pro-Set 600 and Pro-Set 700. Where noted,
use the alternate addresses for the singular combination of Pro-Set
600 and the clamp/Eject mode of operation.
Command
Block:
Block
ID: Page:
Status
Block:
Block
ID: Page:
CLC 27 1-2 CLS 27 1-36
CPC 7 1-3 CPS 7 1-37
DYC 25 1-4
EAC 22 1-5
EPC 24 1-6 EPS 24 1-39
ERC 23 1-7
FCC 3 1-8
FOC 17 1-10
HDC 11 1-11
HPC 12 1-13 HPS 12 1-40
INC 8 1-14
IPC 9 1-15 IPS 9 1-41
JGC 2 1-16
LPC 6 1-18
MCC 1 1-19 SYS 1 1-47
OPC 21 1-21 OPS 21 1-42
OSC 20 1-22
PKC 10 1-23
PLC 14 1-24
PPC 15 1-26 PPS 15 1-44
PRC 13 1-27
PSC 16 1-28
PTC 28 1-29 PTS 28 1-45
RLC 26 1-30 RLS 26 1-46
SCC 4 1-30
SOC 18 1-32
TCC 5 1-33
TOC 19 1-35
