3–47 Status Word/Bit Descriptions
Publication 1771-6.5.88 – July 1997
SYS
Cycle Maximum Pressures
Word Description
SYS49 Maximum Ram (Screw) Pressure During Last Cycle [01]
If bit patterns in MCC02 and MCC03 indicate that the module is connected to a ram (screw) pressure transducer but
not a clamp
position transducer, the module reports the highest ram (screw) pressure it detected since the last F-to-T transition of DYC02-B04.
If bit patterns in MCC02 and MCC03 indicate that the module is connected to a clamp position transducer, the module reports the
highest ram (screw) pressure it detected since the last F-to-T transition of DYC02-B00.
SYS50 Maximum Clamp Pressure During Last Cycle [02]
If bit patterns in MCC02 and MCC03 indicate that the module is connected to a clamp pressure transducer, the module reports the
highest clamp pressure it detected since last F-to-T transition of DYC02-B00.
SYS51 Maximum Ejector Pressure During Last Cycle [03]
If bit patterns in MCC02 and MCC03 indicate that the module is connected to a ejector pressure transducer, the module reports the
highest ejector pressure it detected since last F-to-T transition of DYC02-B00.
SYS52 Maximum Cavity (or System) Pressure During Last Cycle [04]
If bit patterns in MCC02 and MCC03 indicate that the module is connected to a cavity pressure transducer but
not a clamp position
transducer, the module reports the highest cavity pressure it detected since the last F-to-T transition of DYC02-B04.
If bit patterns in MCC02 and MCC03 indicate that the module is connected to both a cavity pressure transducer and a clamp position
transducer, the module reports the highest cavity pressure it detected since the last F-to-T transition of DYC02-B00.
If MCC02-B03, B04, B05 are all set, (inject/clamp/eject mode) the module reports the highest system pressure it detected since the
last F-to-T transition of DYC02-B00.
If MCC02-B03 is set with B04, B05 in opposite states (inject/clamp mode or clamp/eject mode) module will not report data in this word
Process Trace Data Collection Status
Word Bit Description
SYS53 Process Trace status
B00 Process Trace data collection in progress.
B01 Process Trace data collection complete.
B02 - B15 Open
SYS54 Process Trace data collection in progress
B00 The module is collecting trace data points 1 to 50.
B01 The module is collecting trace data points 51 to 100.
B02 The module is collecting trace data points 101 to 150.
B03 The module is collecting trace data points 151 to 200.
B04 The module is collecting trace data points 201 to 250.
B05 The module is collecting trace data points 251 to 300.
B06 The module is collecting trace data points 301 to 350.
B07 The module is collecting trace data points 351 to 400.
B08 - B15 Open
SYS55 Process Trace data collection done
B00 The module has collected trace data points 1 to 50.
B01 The module has collected trace data points 51 to 100.
B02 The module has collected trace data points 101 to 150.
B03 The module has collected trace data points 151 to 200.
B04 The module has collected trace data points 201 to 250.
B05 The module has collected trace data points 251 to 300.
B06 The module has collected trace data points 301 to 350.
B07 The module has collected trace data points 351 to 400.
B08 - B15 Open
SYS56 Open
