4–39 Programming Error Codes
Publication 1771-6.5.88 – July 1997
Error Code Description ID = 16
0240 PSC40 is out of range. Valid range is 00000
≤
PSC40
≤
09999
0405 PSC05 is out of range.
if:
then:
MCC13 and MCC14 PSC05 must be within 00000
≤
PSC05
≤
MCC14 – MCC13
are both non-zero
MCC13 is non-zero and PSC05 must be within 00000
≤
PSC05
≤
MCC10 – MCC13
MCC14 is zero
MCC13 is zero and PSC05 must be within 00000
≤
PSC05
≤
MCC14 – MCC09
MCC14 is non-zero
MCC13 and MCC14 PSC05 must be within 00000
≤
PSC05
≤
MCC10 – MCC09
are both zero
0457 PSC57 is out of range.
If non-zero, PSC57 must be within MCC17 < PSC57
≤
MCC18
0905 PSC05 is too large.
if:
then:
MCC13 and MCC14 PSC05 must be within MCC13 + PPC61 + PPC62 + PSC05
are both non-zero
≤
MCC14
MCC13 is zero and PSC05 must be within MCC09 + PPC61 + PPC62 + PSC05
MCC14 is non-zero
≤
MCC14
MCC13 is non-zero and PSC05 must be within MCC13 + PPC61 + PPC62 + PSC05
MCC14 is zero
≤
MCC10
MCC13 and MCC14 PSC05 must be within MCC09 + PPC61 + PPC62 + PSC05
are both zero
≤
MCC10
ID = 17
FOC – First Clamp Open Configuration Block
Error Code Description ID = 17
0205 FOC05 is out of range. Valid range is 00000
≤
FOC05
≤
09999
0206 FOC06 is out of range. Valid range is 00000
≤
FOC06
≤
09999
0208 FOC08 is out of range. Valid range is 00000
≤
FOC08
≤
09999
0209 FOC09 is out of range. Valid range is 00000
≤
FOC09
≤
09999
0210 FOC10 is out of range. Valid range is 00000
≤
FOC10
≤
09999
0211 FOC11 is out of range. Valid range is 00000
≤
FOC11
≤
09999
0212 FOC12 is out of range. Valid range is 00000
≤
FOC12
≤
09999
0213 FOC13 is out of range. Valid range is 00000
≤
FOC13
≤
09999
0214 FOC14 is out of range. Valid range is 00000
≤
FOC14
≤
09999
0215 FOC15 is out of range. Valid range is 00000
≤
FOC15
≤
09999
0216 FOC16 is out of range. Valid range is 00000
≤
FOC16
≤
09999
0217 FOC17 is out of range. Valid range is 00000
≤
FOC17
≤
09999
0218 FOC18 is out of range. Valid range is 00000
≤
FOC18
≤
09999
0219 FOC19 is out of range. Valid range is 00000
≤
FOC19
≤
09999
0220 FOC20 is out of range. Valid range is 00000
≤
FOC20
≤
09999
0221 FOC21 is out of range. Valid range is 00000
≤
FOC21
≤
09999
0222 FOC22 is out of range. Valid range is 00000
≤
FOC22
≤
09999
0223 FOC23 is out of range. Valid range is 00000
≤
FOC23
≤
09999
0224 FOC24 is out of range. Valid range is 00000
≤
FOC24
≤
09999
0225 FOC25 is out of range. Valid range is 00000
≤
FOC25
≤
09999
0226 FOC26 is out of range. Valid range is 00000
≤
FOC26
≤
09999
0227 FOC27 is out of range. Valid range is 00000
≤
FOC27
≤
09999
