2–101 Command Word/Bit Descriptions
Publication 1771-6.5.88 – July 1997
SOC
Bit-mapped Control Words
Word Bit Description
SOC01 Block ID = 00010010 (Low byte). High byte reserved for the module. Do not use.
SOC02 Configuration Selections
B00-B02 Selected Velocity Control Valve
The module uses its algorithm to drive the following output during any Vel/Pos Second Clamp Open Profile.
B02 B01 B00
0 0 0 Output #1
0 0 1 Output #2
0 1 0 Output #3
0 1 1 Output #4
1 0 0 Output #5
1 0 1 Output #6
1 1 0 Output #7
1 1 1 Output #8
B03 Open
B04-B06 Selected Pressure Control Valve
The module uses its algorithm to drive the following output during any Press/Pos Second Clamp Open Profile.
B06 B05 B04
0 0 0 Output #1
0 0 1 Output #2
0 1 0 Output #3
0 1 1 Output #4
1 0 0 Output #5
1 0 1 Output #6
1 1 0 Output #7
1 1 1 Output #8
B07 Pressure Algorithm Selection
= 0 Dependent Gains (ISA)
= 1 Independent Gains (A-B)
B08-B15 Open
SOC03 - 04 Open
Expert Response Compensation (ERC) Percentage
Word Description
SOC05 Minimum Velocity Control ERC Percentage [31]
Although error coding allows range of 00000 to 09999, the module limits it to a minimum of 01000.
SOC06 Minimum Pressure Control ERC Percentage [31]
Although error coding allows range of 00000 to 09999, the module limits it to a minimum of 01000.
SOC07 Open
Watchdog Timer
Word Description
SOC08 Profile Watchdog Timer Preset [21] When the module starts the Second Clamp Open Profile, it:
S starts an internal Profile Watchdog timer
S
stops the timer and reset accumulated value to zero (after reporting total execution time in OPS58) when it completes the profile
S sets master status bit SYS04-B11 when the accumulated value of this timer equals or exceeds this entry.
A zero entry inhibits SYS04-B11.
SOC – Second Clamp
Open Configuration Block
